Diesel Engine | 69.9kW, 2300 RPM | HA694-IRRIGet latest price

It is perfect for pumping applications, including irrigation. All diesel engines that are sold through Welling and Crossley are stringently tested to ensure reliability and quality.

Product Features:

Kirloskar Air cooled HA Series diesel engines are designed for maximum economy and reliability. These power units have the following standard features:

• Pre and micro fuel filters
• Lube oil cooler
• Fuel lift pump
• Lube oil filer
• Engine stop leaver ( hand operated)
• Engine supports suitable for rigid mounting
• Automatic belt tension unit
• Mechanical/electrical engine shut down system in case of ‘V’ belt failure

Product Specifications:

• Power Rating: 69.9 kW
• Engine Model: Kirloskar HA 694
• Torque: 290 Nm/29.6 Kgm
• Bore x Stroke: 100 x 120mm
• Displacement: 5652 cc
• Compression Ratio: 17 : 1
• Rotation while looking at flywheel: Anti-clockwise
• Max. Speed: 2300 rpm
• Min. Speed: 1500
• Low Idling: 650
• Weight: 430 kg
• Dimensions: 1277 x 704 x 922 mm
