Brentwood’s QS50HD Quad Shaft Shredder is designed for shredding large bulky items.

34 Recent Views

More than twice the size of the QS15WL, the QS50HD is suited to shredding large bulky items. With its removable screen, a uniformly sized output is possible. Used for paper, cardboard, bulky plastic and medical waste.

Product Features:

2 x 18.5kW drives
High torque/low speed
120mm hexagonal shaft for superior strength
Wide grab due to upper cutters that grab material and feed it to the lower cutters.
Removable sizing screen
Planetary reduction gearbox
High surface hardness/high core strength repairable alloy cutters
DOL, Smart Start, and Eco Vari Drive control options with auto reverse and overload protection.
Wide range of cutter widths and hook types to suit different materials and output size requirements
Wide range of infeed and discharge options
Australian made for Australian conditions

Product Specifications:

Power	37 kW (2 x 18.5 kW)
Full Load Current	66 amps
DOL Starting Current	536 amps
Shaft Centres (upper/lower)	229/553 mm
Shaft Diameter	120 mm
Standard Cutting Chamber Length	1060 mm
Cutting Chamber Width	820 mm
Machine Length	3127 mm
Machine Width	1300 mm
Machine Height	534 mm
Weight	2,900 kgs
Cutter Width Options	20/31/40/47/62 mm
