Industrial Shredder | AZ100/2 75kW Dual Shaft Shredder

Name: Industrial Shredder | AZ100/2 75kW Dual Shaft Shredder
Brand: Brentwood Recycling Systems

Supplier: Brentwood Recycling Systems

The AZ100/2 is a 75kW machine with 130mm shafts. The distance between shaft centres is 305mm giving this machine an exceptional ability to grab bulky materials. Used for MSW, RDF, paper, timber, tyres, MDF boards and other tough applications.

40 Recent Views

The AZ100/2 is a 75kW machine with 130mm shafts. The distance between shaft centres is 305mm giving this machine an exceptional ability to grab bulky materials. Used for MSW, RDF, paper, timber, tyres, MDF boards and other tough applications.

Product Features:

2 x 37.5kW drives
High torque/low speed
130mm hexagonal shaft for superior strength
Wide “grab” for shredding larger items
Planetary reduction gearbox
High surface hardness/high core strength repairable alloy cutters
DOL and VSD Drive control options with auto reverse and overload protection.
Wide range of cutter widths and hook types to suit different materials and output size requirements
Wide range of infeed and discharge options
Australian made for Australian conditions

Product Specifications:

Power	75 kW (2 x 37.5kW)
Full Load Current	134 amps
DOL Starting Current	1072 amps
Shaft Centres	305 mm
Shaft Diameter	130 mm
Standard Cutting Chamber Length	1498 mm
Cutting Chamber Width	813 mm
Machine Length	3900 mm
Machine Width	1500 mm
Machine Height	765 mm
Weight	8000 kgs
Cutter Width Options	31/47/70/94 mm
