Single Shaft Shredder | MSA-F Series

Name: Single Shaft Shredder | MSA-F Series
Brand: Enerpat

Supplier: Enerpat

The Single Shaft Shredder is a versatile industrial machine designed for efficiently shredding plastics, wood waste, and tyres, making it ideal for recycling operations.

Versatile, high-throughput shredding for efficient material recycling.

The MSA-F Series Single Shaft Shredder is suitable for reducing and processing a wide range of materials into a uniform particle size. It is commonly used to shred plastic bottles, pipes, woven bags, cables, waste wood, industrial paper, domestic rubbish, and electronic waste. The shredder can be tailored with different rotor configurations and screens depending on material and output requirements.

Core Features

Robust V-type rotor with DC 53 specially treated knives—each with four usable cutting edges and adjustable gaps for tailored shredding needs.
Convenient, hydraulically controlled screen system with safety switch and customisable mesh sizes.
Advanced dust leakage groove and sealed chamber with adjustable copper guide blocks for improved hydraulic protection.
High-efficiency electric motor with direct heavy-duty gearbox for reliable power delivery and a damping system to protect the drive components.
Electric cabinet features Siemens/Schneider PLC and touchscreen interface for advanced control and safety.

Operation Principle

Hydraulic material pusher moves material to the blade shaft.
Movable and fixed blades perform high-performance mutual shearing.
Final shredded material passes through a screen—output size determined by mesh.

Typical throughput ranges between 300 kg/hr and over 10,000 kg/hr, depending on the model and application.

Technical Specifications

Model	MSA-F600	MSA-F800	MSA-F1000	MSA-F1200	MSA-F1500
Motor Power (kW)	18.5	37	45	55	75
Shredding Chamber Width (mm)	600	800	1000	1200	1500
Overall Dimensions (mm)	1290 × 1820 × 1730	2800 × 1765 × 2080	2800 × 1980 × 2090	2800 × 2490 × 2135	2850 × 2720 × 2150

CE certified for tough or medium-hard bundled materials.

Applications

Plastic recycling (bottles, pipes, film, woven bags)
Wood waste and industrial paper reduction
Electrical cable, domestic rubbish and e-waste processing
Suitable for further processing or as a final product
