Rotating Telescopic handler | MRT-X 1845 Get latest price

The MRT-X 1845 telescopic handler is equipped with 3 steering modes offering perfect maneuverability, thus adapting to all types of construction sites. Thanks to the rotation of the turret, it is possible to operate in a modular work area without having to move the machine. A true 3-in-1 concept, it can be used in telescopic, aerial platform and winch mode while working on tires or stabilizers, which reinforces its versatility. The MRT-X 1845 has an intelligent dashboard and all the necessary features to guarantee exceptional comfort and ergonomics: panoramic visibility, adjustable cab elements for each operator, safe machine... Simple and powerful, an essential asset to have at your side!

TECHNICAL FEATURES

Capacities

• Max. capacity

  • 4500 kg
• Max. lifting height

  • 18 m
• Max. outreach

  • 15.20 m

Weight and dimensions

• Overall width

  • 2.45 m
• Overall height

  • 3.04 m
• Overall cab width

  • 0.96 m
• Ground clearance

  • 0.37 mm
• Wheelbase

  • 2.43 m
• Tilt-up angle

  • 10 °
• Tilt-down angle

  • 107 °
• Turret rotation

  • 400 °
• Overall weight

  • 14100 kg
• Forks length / width / section

  • 1200 mm x 125 mm x 50 mm

Wheels

• Standard tyres

  • 405/70-20
• Drive wheels (front / rear)

  • 2 / 2
• Steering mode

  • 2 wheel steer, 4 wheel steer, Crab mode

Stabilisers

• Stabs Type

  • Wing Type
• Controls with stabs

  • Stabs Commands Individual or Simultaneous

Engine

• Engine brand

  • Deutz
• Engine norm

  • Stage IIIA / Interim Tier 4
• Engine model

  • TCD 3.6 L4
• I.C. Engine power rating / Power (kW)

  • 116 Hp / 85 kW
• Max. torque / Engine rotation (min)

  • 460 Nm @ 1600 rpm
• Number of cylinders - Capacity of cylinders

  • 4 - 3620 cm³
• Engine cooling system

  • Water cooled
• Number of batteries / Battery / Batteries capacity

  • 2 x 12 V / 120 Ah
• Battery starting current

  • (EN)850 A

Transmission

• Transmission type

  • Hydrostatic
• Number of gears (forward / reverse)

  • 2 2
• Parking brake

  • Automatic negative parking brake
• Service brake

  • Oil-immersed multi-discs braking on front & rear axles

Hydraulics

• Hydraulic pump type

  • Load sensing pump
• Hydraulic flow

  • 116 l/min
• Hydraulic Pressure

  • 275 bar

Tank capacities

• Engine oil

  • 11 l
• Hydraulic oil

  • 144 l
• Fuel tank

  • 130 l

Miscellaneous

• Steering wheels (front / rear)

  • 2 / 2
• Controls

  • 2 Joysticks
• Safety cab homologation

  • ROPS - FOPS cab (level 2)
• Attachment recognition system (E-Reco)

  • Standard
