Motor Graders 150 / 150 AWD - TIER 4 / STAGE 5Get latest price

KEY SPECS

• Net Power Range (Tier 4)
  • 149 kW
• Operating Weight - Typically Equipped
  • 19935 kg
• Blade Width
  • 3.7 m

ENGINE

• Net Power Range (Tier 4)149 kW
• Engine ModelCat® C9.3
• Bore115 mm
• Stroke149 mm
• Speed at Rated Power2,000 rpm
• VHP Plus - Gear - Net Power - Reverse 1st149 kW
• VHP Plus - Gear - Net Power - Forward 1st149 kW
• Maximum Torque - VHP Plus1247 N·m
• VHP Plus - Gear - Net Power - Forward 8th188 kW
• VHP Plus - Gear - Net Power - Forward 6th180 kW
• VHP Plus - Gear - Net Power - Forward 2nd156 kW
• EmissionsU.S. EPA Tier 4 Final/EU Stage V
• VHP Plus - Gear - Net Power - Forward 7th184 kW
• High Ambient - Fan Speed - Standard1,400 rpm
• VHP Plus - Gear - Net Power - Forward 5th176 kW
• VHP Plus Range - Net - Metric149-188 kW (202-255 hp)
• Standard Capability43 °C
• VHP Plus - Gear - Net Power - Reverse 3rd-6th164 kW
• VHP Plus - Gear - Net Power - Forward 4th172 kW
• Base Power (1st Gear) - Net - Metric149 kW
• VHP Plus Range - Net149-188 kW (200-252 hp)
• VHP Plus - Gear - Net Power - Reverse 2nd156 kW
• VHP Plus - Gear - Net Power - Forward 3rd164 kW
• Torque Rise39%
• Displacement9.3 l
• Number of Cylinders6
• Derating Altitude3050 m
• High Ambient - Fan Speed - Maximum1,550 rpm
• High Ambient - Fan Speed - Minimum500 rpm
• High - Ambient Capability50 °C

POWER TRAIN

• Forward/Reverse Gears8 Forward/6 Reverse
• TransmissionAPECS, Direct Drive, Powershift
• Brakes - ServiceMultiple Oil Disc
• Brakes - Service - Surface Area23000 cm²
• Brakes - ParkingMultiple Oil Disc
• Brakes - SecondaryDual Circuit

HYDRAULIC SYSTEM

• Circuit TypeParallel
• Pump TypeVariable Piston
• Pump Output210 l/min
• Maximum System Pressure24150 kPa
• Reservoir Tank Capacity64 l
• Standby Pressure6100 kPa
