This product has incredible flexibility and softness even with cold climate use. The smooth inner and close polyester braiding means a smooth inner bore to assist flow rates. This allows better flow over longer lengths while retaining user comfort and less hose resistance to the hand.
Due to the special properties of Polyurethane hose, a strong and reliable connection between hose and fitting can be achieved, thus eliminating the use of hose clamps.
The Ether polyurethane material has excellent water and oil resistance. Polyurethane material remains the most abrasion resistant material in a hose form. Slightly more costly than conventional PVC / Rubber hoses it consistently returns a much longer life.
Features & Benefits
Best Application
Specifications
Metric Sizes
| Part Number | Hose Size (mm) | Bend Radius (mm) | Colour | Roll Size (metres) |
|---|---|---|---|---|
| EBH-6.5×10-E-NB | 6.5 x 10 | 50 | Navy-Blue | 25m |
| EBH-6.5×10-F-NB | 6.5 x 10 | 50 | Navy-Blue | 100m |
| EBH-8×12-E-NB | 8 x 12 | 60 | Navy-Blue | 25m |
| EBH-8×12-F-NB | 8 x 12 | 60 | Navy-Blue | 100m |
| EBH-11×16-E-NB | 11 x 16 | 80 | Navy-Blue | 25m |
| EBH-11×16-F-NB | 11x 16 | 80 | Navy-Blue | 100m |
| EBH-11×16-E-OR | 11 x 16 | 80 | Orange | 25m |
| EBH-11×16-F-OR | 11 x 16 | 80 | Orange | 100m |
| EBH-11×16-E-G | 11 x 16 | 80 | Green | 25m |
| EBH-11×16-F-G | 11 x 16 | 80 | Green | 100m |
| EBH-11×16-E-R | 11 x 16 | 80 | Red | 25m |
| EBH-11×16-F-R | 11 x 16 | 80 | Red | 100m |
Imperial Sizes
| Part Number | Hose Size (inch) | Bend Radius (mm) | Colour | Roll Size (metres) |
|---|---|---|---|---|
| EBH-3/8-E-CB | 3/8 x 9/16 | 70 | Clear-Blue | 25m |
| EBH-3/8-F-CB | 3/8 x 9/16 | 70 | Clear-Blue | 100m |
| EBH-1/2-E-CB | 1/2 x 3/4 | 80 | Clear-Blue | 25m |
| EBH-1/2-F-CB | 1/2 x 3/4 | 80 | Clear-Blue | 100m |
To contact Advanced Technology Pneumatics about Econobraid PU Braided Hose use Get a quote.
