DTL35 Tracked Skid Steer Loader

Name: DTL35 Tracked Skid Steer Loader
Brand: DWL Machinery

Supplier: DWL Machinery

The DTL35 Tracked Skid Steer Loader is engineered for exceptional power, productivity, and versatility in tough construction and earthmoving tasks.

Outstanding traction and stability on challenging terrain with high lifting capacity.

Key Features

Rated operating capacity: approx. 1,590 kg
High-performance turbo diesel engine
High-flow hydraulic system
Heavy-duty rubber track undercarriage
Enclosed air-conditioned operator cabin
Ergonomic joystick controls for comfort and efficiency
Excellent visibility for enhanced safety
Quick hitch system for rapid attachment changes
Compatible with a wide range of attachments, including buckets, pallet forks, augers, trenchers, slashers, grapples, and more
Designed for demanding construction, landscaping, demolition, agriculture, and material handling jobs

Engine Specifications

Make	DEVELON
Model	D34
Emission Certification	EPA Tier 4 final
Cylinders	4
Rated Power, Gross	86 kW @ 2400 rpm
Rated Power, Net	76.5 kW @ 2400 rpm
Max Torque, Net	46.9 kgfm @ 1400 rpm
Displacement	3.4 L
Starter	12 V, 3.3 kW
Battery	12 V, 150 AH
Aspiration	Turbocharged
Alternator	12 V, 140 amp
Aftertreatment	DOC, SCR (no DPF)

Dimensions

Overall length (with bucket)	4,210 mm
Overall length (without bucket)	3,372 mm
Width (factory bucket)	2,032 mm
Height to top of cab	2,133 mm
Ground clearance	247 mm
Track gauge	1,551 mm
Tumbler distance	1,767 mm
Max. overall height	4,304 mm
Bucket pin height at max. lift	3,280 mm
Clearance at max. lift and dump	2,457 mm

Performance & Capacities

Refill Capacities:
- Fuel tank: 110 L
- DEF tank: 15 L
- Cooling system: 14 L
- Engine oil: 14.6 L
- Hydraulic tank: 40 L
- Hydraulic system: 72.7 L
Travel speed: 9.8–14.8 km/h (low/high)
Maximum traction force: 45.6 kN
Main hydraulic pump (standard): 84 L/min @ 2400 rpm
Main hydraulic pump (high flow): 151.2 L/min @ 2400 rpm
Hydraulic pressure (standard): 23,000 kPa
Hydraulic pressure (high): 28,000 kPa

The loader is compatible with buckets, pallet forks, augers, trenchers, slashers, grapples, and more, making it suitable for a variety of commercial, agricultural, and construction tasks.
