Construction Telescopic Handler | MT-X 1440Get latest price

The MT-X 1440 telehandler is designed for sites requiring increased lift height. Featuring a lift capacity of 4 tonnes up to heights of 14 m, you can safely remove loads thanks to the broad outriggers which give you excellent lateral and front stability. It also can handle all types of terrain with its 4-wheel drive and steering capabilities and generous ground clearance. Designed with easily accessible slinging points, moving the MT-X 1440 from one site to another is a breeze. The quality of components used and low frame steel door ensure long-lasting durability, while the large engine hood makes maintenance a snap.

Capacities

• Max. capacity

  • 4000 kg
• Max. lifting height

  • 13.53 m
• Max. outreach

  • 9.46 m
• Breakout force with bucket

  • 8000 daN

Weight and dimensions

• Overall length to carriage

  • 6.02 m
• Overall width

  • 2.42 m
• Overall height

  • 2.45 m
• Wheelbase

  • 3.07 m
• Ground clearance

  • 0.37 m
• Overall cab width

  • 0.89 m
• Tilt-up angle

  • 12 °
• Tilt-down angle

  • 114 °
• External turning radius (over tyres)

  • 3.94 m
• Unladen weight (with forks)

  • 11115 kg
• Tyres type

  • Pneumatic
• Standard tyres

  • Alliance 400/80 - 24 - 162A8
• Forks length / width / section

  • 1200 mm x 125 mm / 50 mm

Performances

• Lifting
  • 15.50 s
• Lowering

  • 11.60 s
• Extension

  • 16.50 s
• Retraction

  • 11.90 s
• Crowd

  • 3.90 s
• Dump

  • 4 s

Engine

• Engine brand

  • Perkins
• Engine norm

  • Stage IIIA
• Engine model

  • 1104D-44TA
• Number of cylinders / Capacity of cylinders

  • 4 - 4400 cm³
• I.C. Engine power rating - Power (kW)

  • 101 Hp / 74.50 kW
• Max. torque / Engine rotation

  • 400 Nm @ 1400 rpm
• Drawbar pull (Laden)

  • 8250 daN

Transmission

• Transmission type

  • Torque Converter
• Number of gears (forward / reverse)

  • 4 / 4
• Max. travel speed

  • 24.90 km/h
• Parking brake

  • Automatic Negative Hand-brake
• Service brake

  • Oil-immersed multi-discs braking on front & rear axles

Hydraulics

• Hydraulic pump type

  • Gear pump
• Hydraulic flow / Pressure

  • 167 l/min / 270 bar

Tank capacities

• Engine oil

  • 11.40 l
• Hydraulic oil

  • 135 l
• Fuel tank

  • 140 l

Noise and vibration

• Noise at driving position (LpA)

  • 82 dB(A)
• Noise to environment (LwA)

  • 105 dB(A)
• Vibration on hands/arms

  • < 2.50 m/s²

Miscellaneous

• Steering wheels (front / rear)
  • 2 / 2
• Drive wheels (front / rear)

  • 2 / 2
• Safety cab homologation

  • ROPS - FOPS cab (level 2)
• Controls

  • JSM
