Construction Telescopic handler | MT 730 H Get latest price

Capacities

• Max. capacity

  • 3000 kg
• Max. lifting height

  • 6.90 m
• Max. outreach

  • 4 m

Weight and dimensions

• Overall length to carriage

  • 4.67 m
• Overall length (with forks)

  • 5.77 m
• Overall width

  • 1.99 m
• Overall height

  • 1.99 m
• Wheelbase

  • 2.69 m
• Ground clearance
  • 0.34 m
• Overall cab width
  • 0.79 m
• Tilt-up angle

  • 11 °
• Tilt-down angle

  • 116 °
• External turning radius (over tyres)

  • 3.33 m
• Unladen weight (with forks)

  • 5880 kg
• Standard tyres

  • ALLIANCE 380/75 R20 148A8 A580
• Forks length / width / section

  • 1070 mm x 100 mm / 50 mm

Performances

• Lifting

  • 9.42 s
• Lowering

  • 7.53 s
• Extension

  • 7.43 s
• Retraction

  • 9.36 s
• Crowd

  • 3.21 s
• Dump

  • 2.15 s

Engine

• Engine brand

  • Kubota
• Engine norm

  • Stage V
• Engine model

  • V3307-CR-TE5B
• Number of cylinders / Capacity of cylinders

  • 4 - 3331 cm³
• I.C. Engine power rating - Power (kW)

  • 75 Hp / 54.60 kW
• Max. torque / Engine rotation

  • 265 Nm @ 1400 rpm
• Drawbar pull (Laden)

  • 3860 daN

Transmission

• Transmission type

  • Hydrostatic
• Number of gears (forward / reverse)

  • 2 / 2
• Max. travel speed

  • 24.90 km/h
• Service brake

  • Hydraulic

Hydraulics

• Hydraulic pump type

  • Gear pump
• Hydraulic flow / Pressure

  • 88 l/min / 245 bar

Tank capacities

• Engine oil

  • 11 l
• Hydraulic oil

  • 115 l
• Fuel tank

  • 90 l

Noise and vibration

• Noise at driving position (LpA)

  • 74 dB(A)
• Noise to environment (LwA)

  • 103 dB(A)
• Vibration on hands/arms

  • < 2.50 m/s²

Miscellaneous

• Steering wheels (front / rear)

  • 4 / 4
• Safety cab homologation

  • ROPS - FOPS cab (level 2)
